Iceblink
PRO
V1
Supercontinuum Fiber Laser with Variable Frequency
Spectral Range:
410 – 2300 nm
Average Power: ≥ 2 W @ 40 MHz (fundamental frequency)
Visible Range Average Power (410-850 nm):
≥ 150 mW @ 40 MHz
Tunable Pulse Repetition Rate:
40 / 20 / 10 / 5/ 2.5 / 1 MHz / 500kHz
Adjustable repetition rates
Equipped with a pulse picker for enhanced control
This supercontinuum fiber laser spans a spectral range of 410 – 2300 nm and is equipped with a pulse picker for enhanced control.
The pulse picker enables users to select specific laser pulses, allowing for adjustable repetition rates and tailored light output.
This feature makes the Iceblink with variable frequency ideal for precise, time-sensitive applications. Its spatial coherence and broad spectrum makes it a strong alternative to traditional lamps, single-line lasers, LEDs, and ASE sources, supporting scientific and industrial uses like fluorescence lifetime imaging, time-resolved spectroscopy and other.
Technical Specifications
Average Power
≥ 2 W @ 40 MHz
Visible Range (410-850 nm) Average Power:
≥ 150 mW @ 40 MHz
Pulse Duration
≤ 10 ps @ 1060 nm | ≤ 250 ps full spectrum****
Power Stability
≤ 0.5 % (std. dev.)
Polarization
Unpolarized
Output Port
Single Mode Fiber, 1.0 m length (customizable)
Optical Output
Collimated (in the range 450 - 1000 nm), Single-mode across full spectrum
Synchronization / Connections
TTL (SMA) ; NIM (SMA) Under request
Beam Diameter @ 1 m of distance
@ 470 nm ≤ 2 mm/@ 580 nm ≤ 2.5 mm / @ 725 nm ≤ 3.5 mm/@ 1150 nm ≤ 5.5 mm
Spatial Mode Quality (M2 )
≤ 1.2
Cooling
Thermoelectric cooler + air cooling
Power Requirements
110V - 220V / 50Hz-60Hz
Operating Temperature
20 - 30 ºC
Storage Temperature
0 - 60 ºC
Dimensions
436x560x151 mm (WxDxH)
Control:
Manual / Software via USB
Safety Connections:
Interlock / Key
Optical Spectrum
Security
This product is a Class 4 laser. Appropriate safety measures according to such laser class should be taken in its installation and use SPECTRAL PROFILE AND OTHER DETAILED SPECS UNDER REQUEST
SPECTRAL PROFILE AND OTHER DETAILED SPECS UNDER REQUEST
*Customizable
**Other values under request
***Minimum frequency
****Estimated value
Laser
Accessory
Boreal - Tunable Visible Range
Is the accessory for supercontinuum lasers to choose any wavelength in the visible range (400 - 1000 nm). The perfect white laser plug-in accessory for bioimaging, nanophotonic and more.
Boreal - V1 Tunable NIR Range
Is the accessory for supercontinuum lasers to choose any wavelength in the NIR range (1000 - 1700 nm). The perfect white laser plug-in accessory for NIRS, and Optical Characterization of Device.
Iceblink PRO Applications & References
Iceblink PRO for Optical characterization of material and devices, Life Science Microscopy and Astronomical Research.
Enhanced Light Sheet Elastic Scattering Microscopy by Using a Supercontinuum Laser
Light sheet fluorescence microscopy techniques have revolutionized biological microscopy enabling low-phototoxic long-term 3D imaging of living samples. Although there exist many light sheet microscopy (LSM) implementations relying on fluorescence, just a few works have paid attention to the laser elastic scattering source – Read more.
Diego Di Battista, David Merino, Giannis Zacharakis, Pablo Loza-Alvarez and Omar E. Olarte
Feasibility of supercontinuum sources for use in glucose sensing by absorption spectroscopy
Diabetes mellitus 1 requires tight control of the blood glucose levels to avoid harmful effects of either too high (hyperglycemia) or too low (hypoglycemia) blood sugar. Due to the availability of low-cost components, fiber-coupled near infrared (NIR) absorption spectroscopy could be a feasible measurement method. – Read more.
Silje S. Fuglerud, Karolina Milenko, Reinold Ellingsen, Astrid Aksnes, and Dag R. Hjelme
Using fiber-optic sensors to give insight into liquid-solid phase transitions in pure fluids and mixtures.
Fiber optic sensors offer a new and unique way to detect and analyze phase transitions, due to their small thermal mass and inert material. This paper presents and demonstrates a dual-sensor system to detect and analyze phase transitions in pure water and aqueous ethanol mixtures. – Read more.
Markus Solberg Wahl, Øivind Wilhelmsen, Dag Roar Hjelme
need more information?
Iceblink PRO FAQs
What Is FYLA Iceblink Pro with Variable Frequency, and How Does It Differ from Standard Supercontinuum Fiber Lasers?
FYLA Iceblink Pro is a variable‑frequency supercontinuum laser covering 410 to 2300 nm. Unlike fixed‑repetition‑rate systems, it integrates pulse picking that allows repetition rates from 40 MHz down to 500 kHz, enabling precise temporal control for time‑sensitive optical techniques.
Why Is FYLA Iceblink Pro with Variable Frequency Suitable for Fluorescence Lifetime Imaging (FLIM)?
FLIM requires controlled excitation timing to accurately resolve fluorescence decay lifetimes. FYLA Iceblink Pro provides:
- Tunable repetition rates down to 500 kHz
- High power stability (≤ 0.5 % std. dev.)
- Broad spectral excitation from VIS to NIR
Can FYLA Iceblink PRO with Variable Frequency be used for Time-correlated Single-photon Counting (TCSPC)?
Yes. FYLA Iceblink Pro is specifically suited for TCSPC applications thanks to its controllable pulse repetition rate and stable pulse output. Adjusting the repetition rate allows users to match the laser excitation to detector and electronics dead times, improving photon statistics and avoiding pile‑up effects.
How does FYLA Iceblink PRO with Variable Frequency Compare to Lamps, LEDs, and Single-line lasers?
Compared to traditional lamps, LEDs, or single-wavelength lasers, Iceblink Pro offers:
- Higher brightness and spatial coherence
- Continuous broadband spectrum
- Precise temporal control via pulse picking
This makes it a single-source alternative to multiple discrete emitters, improving experimental flexibility and repeatability in advanced optical setups.
What Applications Benefit Most from FYLA Iceblink Pro Supercontinuum Fiber Laser with Variable Frequency?
FYLA Iceblink Pro is particularly well-suited for:
- Fluorescence lifetime imaging microscopy (FLIM)
- Time-resolved spectroscopy
- TCSPC and lifetime measurements
- FRET imaging
- Optical characterization of materials and devices
These applications benefit directly from the combination of broadband emission and variable repetition rate.
What are the Main Optical Characteristics of the FYLA Iceblink Pro with Variable Frequency?
Key characteristics of FYLA Iceblink PRO SC Fiber Laser include:
- Spectral range: 410–2300 nm
- Average power: ≥ 2 W @ 40 MHz
- Pulse duration: ≤ 10 ps at 1060 nm (≤ 250 ps full spectrum)
- Power stability: ≤ 0.5 % (std. dev.)
- Single-mode spatial quality (M² ≤ 1.2)
These features ensure stable, reproducible illumination for demanding scientific experiments.
How does FYLA Boreal Tunable Filter complement FYLA Iceblink Pro Supercontinuum Fiber Laser with Variable Frequency?
When precise wavelength selection is required, FYLA Iceblink Pro can be combined with FYLA Boreal tunable VIS or NIR filters, enabling narrowband excitation from the broadband supercontinuum output. This combination allows users to maintain temporal control while selecting exact excitation wavelengths for spectroscopy or bioimaging applications.
